**Key Features:**
– Precision-engineered for 532nm and 1064nm lasers
– Imported from Germany; CE and FDA certified
– Approved for diverse laser wavelengths: 266nm, 355nm, 532nm, and 1064nm
– Specifically designed for Leica and Zeiss microscopes
**Product Specifications:**
– Application: Nd:YAG (266nm, 355nm, 532nm, 1064nm), Ti:Sapphire, Fiber, Disc
– Material: Special plastic
– Filter Color: Amber
– Filter Thickness: Approx. 4.0 mm
– Visible Light Transmission (VLT): Approx. 25%
– Diameter: 18.10 mm (Tolerance: ± 0.5 mm)
**EN 12254 Protection Levels:**
– DAB5+IRAB3 (OD10+): >180nm to 315nm
– DAB5+IRAB7+MAB8 (OD9+): >315nm to 532nm
– DAB6+IRAB7+MAB9 (OD9+): >847nm to 1072nm
*Note: Laser filters safeguard doctors’ eyes during laser surgeries. Models available for Carl Zeiss and Leica Operation Microscopes.*
| Weight | 1 kg |
|---|---|
| Dimensions | 20 × 15 × 15 cm |
| 1064nm Laser Filter | 532nm Laser Filter | |||
| D AB5 + IR AB3 (OD 10+) | 180-315 | D AB5 + IR AB3 (OD 10+) | 180-315 | |
| D AB5 + IR AB7 + M AB8 (OD 9+) | >315-532 | D AB6 + IR AB7 + M AB6 (OD 9+) | 315 – 532 | |
| DIRM AB4 (OD 4+) | >532 – 541 | DIRM AB4 ( OD 4+) | >532-540 | |
| DIRM AB3 (OD 3+) | >541-544 | DIRM AB2 (OD 2+) | >540-548 | |
| DIRM AB2 (OD 2+) | > 544-549 | DIRM AB1 (OD 1+) | >548-553 | |
| DIRM AB1 (OD 1+) | >549-555 | |||
| DIRM AB1 (OD 1+) | >690-722 | |||
| IRM AB2 (OD 2+) | >722-745 | |||
| DIRM AB3 (OD 3+) | >745-765 | |||
| IRM AB4 (OD 4+) | >765-780 | |||
| DIRM AB5 (OD 5+) | >780-800 | |||
| DIRM AB6 (OD 6+) | >800-815 | |||
| D AB6 + IRM AB7 (OD 7+) | >815-830 | |||
| D AB6+ IR AB7 + M AB8 ( OD 8+) | >830-847 | |||
| D AB6 + IR AB7 + M AB9 (OD 9+) | >847-862 |
|
||
| D AB6 + IR AB7 + M AB9 (OD 10+) | >862-1065 | |||
| D AB6 + IR AB7 + M AB9 (OD 9+) | >1065-1072 | |||
| D AB6+ IR AB7 + M AB8 (OD 8+) | >1072-1077 | |||
| D AB6 + IRM AB7 (OD 7+) | >1077-1083 | |||
| DIRM AB5 (OD 5+) | >1083-1094 | |||
| DIRM AB4 (OD 4+) | >1094-1102 | |||
| DIRM AB3 (OD 3+) | >1102-1112 | |||
| DIRM AB2 ( OD 2+) | >1112-1125 | |||
| DIRM AB1 ( OD 1+) | >1125-1150 | |||
